AGF Mower

Availability:
Quantity:

Specifications


Heavy Verge Flail Mower/AGF Series Mower (Mulcher)

Uses:

- The Verge Flail Mowers are flail mowers with hydraulic arm for clearing larger, wider areas, roadsides verges, orchards and various inclining and declining land surfaces;

- Specially designed for universal use the head of the mower can be operated in line with the tractor or offset for verge maintenance and field boundaries.
Features:

- The verge Mowers are suitable for roadside verge, tree trimming and general mulching;

- Hydraulic side adjustment;

- Hydraulic inclining adjustment;

- Rear roller wheel;

- High power 50hp gearbox;

- Self leveling;

- High strength mulching blades;

- Safety flaps;

- Extra strong and designed with safety in mind;

- Support legs for storage;

- Solid hitch.


TOWNSUNNY AGF Series Mower Specifications


MODEL

AGF-140

AGF160

AGF-180

AGF-200

AGF-220

DIMENSIONS(L*W*H)

1800*1850*1020mm

2000*1850*1020mm

2200*1850*1020mm

2400*1850*1020mm

2600*1850*1020mm

STRUCTURE WEIGHT

598kg

628kg

658kg

688kg

738kg

CUTTING WIDTH

1400mm

1600mm

1800mm

2000mm

2200mm

WORKING EFFICIENCY

4600-12400m2/h

5300-14200m2/h

6000-16000m2/h

6700-17800m2/h

7400-19600m2/h

PTO TURNNING SPEED

540r/min

540r/min

540r/min

540r/min

540r/min

PTO SPLINE

6*8*1600mm

6*8*1600mm

6*8*1600mm

6*8*1600mm

6x8x1600mm

POWER REQUIRED

40-85HP

50-85HP

55-85HP

60-100HP

70-100HP
