How to maintain the rotary seeding machine?

Rotary tilling and seeding machine is a common agricultural machine, which can realize the simultaneous completion of tilling and seeding, and improve the working efficiency. In order to maintain its performance and extend its service life, regular maintenance and maintenance is very important. Here are some maintenance points:

1. Daily check-ups

- Fastening bolts: Regularly check whether the bolts on the machine are loose, especially the parts with large vibration, such as the plow knife, sowing tray, gear box, etc., loose bolts need to be tightened immediately.

- Lubrication maintenance: The various moving parts of the rotary sowing machine, such as bearings, chains, gears, etc., need to be regularly filled with lubricating oil or grease to maintain the normal operation of the lubrication system and reduce the risk of wear and sticking.

- Oil check: Check the oil level of the gearbox and engine regularly to ensure that the oil is sufficient, and change the oil regularly according to the instructions.

2. Check the ploughing knife

- Tool wear: Rotary farming knife is one of the most seriously worn parts in the work, regularly check the sharpness of the blade. If the tool is found to be seriously worn, it should be replaced in time to ensure the quality and efficiency of farming.

Cleaning the plow knife: After the operation, especially when working in the soil or the plot with high humidity, the plow knife is easy to adhere to soil, weeds, etc., and should be cleaned in time after the end of the work to prevent long-term accumulation leading to rust of the plow knife.

3. Seeding system maintenance

- Seed box inspection: Before and after seeding operation, the seed box should be checked for leakage or blockage, to ensure that the inside of the seed box is dry and free of foreign matter, and regularly clean the dust and residual seeds in the seed box.

- Seeding pipe and seeding port inspection: the seeding pipe and seeding port should be kept unblocked, and the residue should be cleaned regularly to avoid blockage, so as not to affect the seeding effect.

4. Transmission system maintenance

- Belt tension: check the tightness of the transmission belt, the belt too loose may lead to slippage, affecting the transmission efficiency; Too tight will increase the wear speed of the belt. Adjust belt tightening according to the actual situation.

- Chain maintenance: Check the wear of the chain and lubricate or replace it as needed to maintain the stability of the transmission system.

5. Check the hydraulic system

- Oil inspection: Check whether the oil of the hydraulic system is sufficient and whether there is leakage, and supplement or replace the hydraulic oil if necessary.

- Hydraulic pipe: Check the hydraulic pipe regularly for aging or damage. If oil leakage or damage is found, replace the hydraulic pipe in time.

6. Electrical system maintenance

- Circuit inspection: Check whether the electrical circuit is aging, damaged or loose, especially after operation to ensure that the electrical equipment is free of moisture or soil cover, to prevent short circuit or damage.

- Battery maintenance: If equipped with a battery, check the battery voltage regularly, keep the battery terminal clean, and replenish the electrolyte if necessary.

7. Clean and store after operation

- After each operation, the whole machine should be cleaned, especially the rotating ploughing part, the sowing part and the transmission part, and the soil, seeds and other debris should be removed.

- When not used for a long time, the machine should be parked in a dry and ventilated place, and do a good job of rust prevention. Anti-rust oil can be applied to exposed metal parts to prevent rust.

8. Regular maintenance

- Perform regular and comprehensive overhaul and maintenance according to the instructions. For wear parts, wear parts such as belts, ploughing knives, etc., should be replaced in time.

- Every year or after a period of use, it is best to send it to a professional maintenance station for major maintenance to ensure the normal operation of various functions.

Sum up

The maintenance points of the rotary sowing machine include daily inspection, lubrication, cleaning and regular maintenance, especially paying attention to the wear of the ploughing knife, sowing system and transmission components. Regular maintenance can not only extend the service life of the machine, but also improve working efficiency and reduce the failure rate.
