Product Advantage |
Wide Cutting Capacity:
120 cm working width; Covers large areas quickly; Improves mowing efficiency
Equipped with multiple flail blades; Handles thick grass, weeds, and light brush; Provides clean and even cutting.
Compatible with ATV / UTV / small tractors; Simple hitch connection; Easy to transport and operate.
Available with Loncin / Jiangdong / B&S engines; Stable performance and strong power output; Suitable for continuous operation.
Heavy-duty steel frame; Strong resistance to impact and wear; Long service life.
Technical Parameters |
Mod. | Blade | Hammer | Belt | Width | Length | Height | Weight | Engine |
No. | mm | Kg | ||||||
ATV120 | 28 | 56 | 3 | 1745 | 1840 | 910 | 234 | LONGXING |
28 | 56 | 3 | JIANGDONG | |||||
28 | 56 | 3 | B&S | |||||
Customized category | Custom Options (English) |
Appearance and brand | Custom color (Pantone available) |
Logo & brand customization | |
Nameplate customization | |
Customized packaging | |
Mowing system | Cutting width options |
Adjustable cutting height | |
Blade type (rotary / heavy-duty) | |
power system | Engine power options |
Manual start / electric start | |
Structure and Performance | Reinforced chassis |
Safety cover design | |
Belt drive configuration | |
Tow bar design | |
Wheel size & type | |
security configuration | Anti-splash guard |
Safety protection system | |
Emergency stop (optional) | |
Certification and Market | CE certification support |
Market-specific compliance | |
Service and delivery | OEM & ODM service |
Product Uses |
 | Perfect for: ✔ Orchard grass cutting ✔ Farm and pasture maintenance ✔ Roadside vegetation control ✔ Field and garden mowing ✔ Rough terrain grass clearing |
Product Operate Guide |
User Guide (Usage Instructions) | ||||
Installation | Start the Machine | Operation | After Use | Maintenance Tips |
Attach the mower to your ATV/UTV or small tractor using the hitch system, Ensure all bolts and connections are securely tightened, Check engine oil and fuel before operation. | Fill with gasoline (or check fuel level), Start the engine (manual or electric start), Let the machine idle for 1–2 minutes before working. | Adjust cutting height if needed, Drive the ATV at a steady speed Avoid sudden turns or excessive speed on rough terrain, Keep a safe distance from people and obstacles. | Turn off the engine and disconnect power, Clean grass and debris from blades, Check blades and fasteners regularly. | Regularly change engine oil, Inspect belts and blades, Lubricate moving parts, Store in a dry place. |
Product Video |
FAQ |
1. What kind of grass can it cut?
It can handle thick grass, weeds, and light bushes.
2. Is it suitable for uneven terrain?
Yes, it is designed for rough, uneven, and orchard terrain.
3. How wide is the cutting area?
The standard cutting width is 120 cm.
4. Is it easy to maintain?
Yes. The structure is simple, and maintenance is low-cost and easy.
