The transmission shaft is equipped with a clutch hub as standard to prevent equipment damage from overload
540rpm gearbox, with 4 different tool shaft speeds to choose from by adjusting different combinations of gear pairs
Each disc has 6 blades for better soil crushing effect
Side gear transmission, oil bath lubrication
The gearbox on both sides of the cutter shaft is sealed with floating oil seals, which are waterproof and dustproof.
The pressure of the retaining plate can be adjusted by springs
In rocky or hard soil conditions, the cutterhead can be optionally equipped with a docking flange type.
| type | gld-155 | gld-180 | gld-205 | gld-230 |
| Tractor Power (HP) | 45-100 | 50-100 | 60-100 | 70-100 |
| Working Width (cm) | 160 | 185 | 210 | 235 |
| Machine Width (cm) | 173 | 198 | 223 | 248 |
| Weight (kg) | 155 | 180 | 205 | 230 |
| PTO (rpm) | 540 | 540 | 540 | 540 |
| Number of Blades | 36 | 42 | 48 | 54 |
| Spindle Speed (rpm) | 140-174-215-266 | 140-174-215-266 | 140-174-215-266 | 140-174-215-266 |
