Product Advantage
Strong adaptability: compatible with 18-30 horsepower tractors, three-point suspension, quick installation.
Lightweight and durable: The overall structure is lightweight, suitable for small-scale farmland and economic crop areas.
Good homework effect: fine soil and high flatness can effectively improve the germination rate of seeds.
Reasonable tool design: using L-shaped or C-shaped blades, the plowing depth can reach 12-18cm.
Labor saving: one-time molding, reducing the number of cultivation times, saving time and fuel.
Easy maintenance: The transmission structure is compact, the parts are versatile, and easy to repair and maintain.
Technical Parameters
| TL light type rotary tillers | ||||||||
| Model | Working width(cm) | Blades shaft speed(rpm) | Number of blades | Tilling depth(cm) | Fitted power(hp) | Net weight(kg) | Gross weight(kg) | Size（cm） |
| TL85 | 85 | 210 | 16 | 8-12 | 18 | 120 | 152 | 105*73*73 |
| TL95 | 95 | 210 | 16 | 8-12 | 20 | 128 | 160 | 115*73*73 |
| TL105 | 105 | 210 | 20 | 8-12 | 22 | 138 | 172 | 125*73*73 |
| TL115 | 115 | 210 | 24 | 8-12 | 22-25 | 148 | 182 | 135*73*73 |
| TL125 | 125 | 210 | 28 | 8-12 | 25-30 | 158 | 192 | 145*73*73 |
| TL135 | 135 | 210 | 28 | 8-12 | 30-35 | 168 | 202 | 155*73*73 |
Product Uses
1.Vegetable greenhouse cultivation: Loosening and breaking the soil into fine particles is beneficial for crop growth.
2.Orchard management: Loosening soil and weeding between trees to improve soil permeability.
3.Small farmland: land preparation for small and medium-sized farmland such as rice fields, corn fields, wheat fields, etc.
4.Mountain/Hill: Lightweight structure, more suitable for fields with complex terrain
Product Operate Guide
Installation and Connection:
Attach the rotary tiller to the three-point suspension mechanism of the tractor.
Connect the power output shaft (PTO) and ensure it is securely fixed.
Pre homework inspection:
Check the installation direction, fasteners, and lubricating oil of the blade.
Adjust the depth of rotary tillage (usually 12-20cm).
Set the appropriate speed of the tractor (usually 540 revolutions per minute).
Rotary tillage operation:
Start the tractor and slowly lower the rotary tiller.
Keep moving forward at an appropriate speed to avoid overloading operations.
Ensure even cultivation and reduce speed appropriately when encountering hard soil.
Homework completion and maintenance:
Lift the rotary tiller, turn off the PTO, and turn off the engine.
Clean up the soil and weeds, and inspect the fasteners.
Store in a dry place, the blades can be coated with anti rust oil.
Product Advantage
Strong adaptability: compatible with 18-30 horsepower tractors, three-point suspension, quick installation.
Lightweight and durable: The overall structure is lightweight, suitable for small-scale farmland and economic crop areas.
Good homework effect: fine soil and high flatness can effectively improve the germination rate of seeds.
Reasonable tool design: using L-shaped or C-shaped blades, the plowing depth can reach 12-18cm.
Labor saving: one-time molding, reducing the number of cultivation times, saving time and fuel.
Easy maintenance: The transmission structure is compact, the parts are versatile, and easy to repair and maintain.
Technical Parameters
| TL light type rotary tillers | ||||||||
| Model | Working width(cm) | Blades shaft speed(rpm) | Number of blades | Tilling depth(cm) | Fitted power(hp) | Net weight(kg) | Gross weight(kg) | Size（cm） |
| TL85 | 85 | 210 | 16 | 8-12 | 18 | 120 | 152 | 105*73*73 |
| TL95 | 95 | 210 | 16 | 8-12 | 20 | 128 | 160 | 115*73*73 |
| TL105 | 105 | 210 | 20 | 8-12 | 22 | 138 | 172 | 125*73*73 |
| TL115 | 115 | 210 | 24 | 8-12 | 22-25 | 148 | 182 | 135*73*73 |
| TL125 | 125 | 210 | 28 | 8-12 | 25-30 | 158 | 192 | 145*73*73 |
| TL135 | 135 | 210 | 28 | 8-12 | 30-35 | 168 | 202 | 155*73*73 |
Product Uses
1.Vegetable greenhouse cultivation: Loosening and breaking the soil into fine particles is beneficial for crop growth.
2.Orchard management: Loosening soil and weeding between trees to improve soil permeability.
3.Small farmland: land preparation for small and medium-sized farmland such as rice fields, corn fields, wheat fields, etc.
4.Mountain/Hill: Lightweight structure, more suitable for fields with complex terrain
Product Operate Guide
Installation and Connection:
Attach the rotary tiller to the three-point suspension mechanism of the tractor.
Connect the power output shaft (PTO) and ensure it is securely fixed.
Pre homework inspection:
Check the installation direction, fasteners, and lubricating oil of the blade.
Adjust the depth of rotary tillage (usually 12-20cm).
Set the appropriate speed of the tractor (usually 540 revolutions per minute).
Rotary tillage operation:
Start the tractor and slowly lower the rotary tiller.
Keep moving forward at an appropriate speed to avoid overloading operations.
Ensure even cultivation and reduce speed appropriately when encountering hard soil.
Homework completion and maintenance:
Lift the rotary tiller, turn off the PTO, and turn off the engine.
Clean up the soil and weeds, and inspect the fasteners.
Store in a dry place, the blades can be coated with anti rust oil.
