Product Advantage |
3.8kW Yamaha MZ175, stable and reliable
34 L/min flow rate, 6–10m spray range
280L capacity for extended operation
Excellent performance on slopes and rough terrain
Three-cylinder plunger pump for long service life
6F + 2R gears, easy operation
Technical Parameters |
Model | 3GWZ-34 | |||
Overall Parameters | Net Weight | kg | 230 | |
Overall Dimensions (L×W×H) | mm | 2230×795×1175 | ||
Tank Capacity | L | 280 | ||
Working Pressure | MPa | 2.0～3.5 | ||
Spray Range | m | 6月10日 | ||
Rotational Speed | r/min | 1000 | ||
Liquid Pump Flow Rate | L/min | 34 | ||
Liquid Pump Type | - | Triplex plunger pump | ||
Track Ground Contact Length | mm | 750 | ||
Track Center Distance | mm | 480 | ||
Minimum Ground Clearance | mm | 120 | ||
Engine | Type | - | Air-cooled single-cylinder four-stroke gasoline engine | |
Rated Speed | r/min | 3600 | ||
Rated Power | kW | 3.8（Yamaha MZ175） | ||
Fuel Tank Capacity | L | 4.5 | ||
Travel Performance | Travel | Forward (6 gears) | km/h | 0.4-5.7 |
Speed | Reverse (2 gears) | km/h | 0.6-2.7 | |
Minimum Turning Radius | m | 1.15 | ||
Climbing Capacity | ° | 25（unloaded） | ||
Product Uses |
 | Applications ✔ Orchard spraying (apple, citrus, cherry, etc.) ✔ Farm crop protection ✔ Fertilizer and pesticide application ✔ Hilly and uneven terrain operations |
Product Operate Guide |
User Guide | ||||
Before Operation | Starting the Machine | Spraying Operation | Driving Tips | After Use |
Check fuel level and engine oil (recommended gasoline for Yamaha MZ175) , Ensure all hoses and connections are tight, Fill the tank with properly diluted chemicals, Inspect tracks and make sure no debris is stuck. | Turn on fuel valve, Set choke (for cold start), Pull recoil starter to start engine, Warm up for 1–2 minutes, Adjust throttle to working speed. | Set working pressure: 2.0–3.5 MPa, Adjust nozzle direction and spray range (6–10m), Drive at suitable speed (0.4–5.7 km/h), Maintain steady movement for uniform spraying. | Use low gear for slopes and rough terrain, Avoid sharp turns at high speed , Do not exceed 25° slope (no load), Keep stable speed in orchard rows. | Clean tank and pipelines with clean water, Release system pressure, Check pump and engine condition, Store in dry and ventilated place. |
Product Video |
FAQ |
1. What is the spraying range and efficiency?
A: 6–10m spraying distance with 34 L/min flow rate, ensuring fast and even coverage.
2. Can it work on slopes and rough terrain?
A: Yes. The tracked design allows stable operation on slopes (up to 25°), muddy and uneven ground.
3. What engine does it use? Is it reliable?
A: Powered by Yamaha MZ175 (3.8kW), offering strong, stable, and long-lasting performance.
4. Is it easy to operate?
A: Yes. With 6 forward + 2 reverse gears, it is simple to control, even for beginners.
5. How long can it work without refilling?
A: The 280L large tank supports long continuous operation, improving working efficiency.
