Product Advantage
Remote control operation: Controlled through wireless remote control or mobile app, convenient for users to remotely control.
Automatic navigation: Some high-end models support GPS or LiDAR navigation to achieve automatic mowing.
Obstacle avoidance function: Built in sensors can detect obstacles and adjust the travel route.
Powerful power: Equipped with an electric drive system, it can adapt to different terrains.
Climbing ability: Suitable for complex terrains such as mountains, hills, orchards, etc., some models can adapt to slopes of over 30 °.
Environmental protection and energy conservation: The electric lawn mower has low noise and zero emissions, making it suitable for places with high environmental requirements.
Technical Parameters
| Model | Autonomous Navigation Lawn Mowing Robot
GLD-52DH | Remote-controlled lawn mower robot
GLD-52YK |
|
| Size (mm) | 1800*980*700 | 1800*980*700 |
| weight (kg) | 150±20 | 150±20 |
| Mowing motor power (W) | 3000 | 3000 |
| Walking power (W) | 1000*2 | 1000*2 |
| Battery (V/Ah) | 48/100 | 48/100 |
| Climbing ability (°) | ≥20 | ≥20 |
| Maximum walking speed (km/h) | 4 | 4 |
| Mowing speed (km/h) | 2--4 | 2--4 |
| Minimum turning radius (m) | 0 | 0 |
| Mowing width (cm) | 52 | 52 |
| Cutting height (cm) | 2--10 | 2--10 |
| Homework efficiency (m ²/h) | 3000 | 3000 |
| Remote control distance (m) | 100 | 100 |
| satellite navigation | Y | - |
| Automatic path planning | Y | - |
Product Uses
Orchard: Reduce manual weeding costs and improve operational efficiency.
Parks/Greenbelts: Achieve intelligent maintenance and reduce human dependence.
Slope/Mountain/Wasteland: Adapt to complex terrain and easily complete mowing tasks.
Farm/Ranch: Maintain the cleanliness of farmland and grassland, and improve land utilization efficiency.
Product Operate Guide
1. Check the machine status: Ensure that the battery is sufficient (electric version), check if the blades are intact, and if the tires or tracks are normal.
2. Environmental inspection: Clean up obstacles such as large rocks and tree branches to avoid affecting the operation of the lawn mower
3. Turn on the remote control and connect the lawn mower.
● Use the directional keys (forward, backward, left, right) to control the movement of the machine.
● Adjust the blade height through remote control or machine panel to meet different lawn needs.
● When working on sloping terrain, maintain stability and avoid the machine tipping over.
